型番:905D1S3J08X、905D2S3J08X、905D3S3J08X、905D4S3J08X、905D5S3J08X、905D4S2L3J08X、905D5S2L3J08X メーカー:LASER COMPONENTS GmbH 商品コード:L001512
波長: 895nm-915nm
出力: 65W-650W
電流: -40A
パッケージ: Hermetic and custom designed package
テクノロジー: High Power Pulsed
< Description >
The 905D series pulsed laser diodes are available as single elements or stacks with a peak power up to 650 W. At an efficiency of 1 W/A, the single elements achieve a peak power of 34 W, whereas the stack designs achieve an output of up to 650 W at a pulse length of 150 ns and a duty cycle of 0.1%.
< Features >
▪ Nanostack devices up to 650 Watts
▪ Proven InGaAs / GaAs high reliability structure
▪ High power large-optical-cavity (LOC) structure for a narrow far-field
▪ Excellent temperature stability
▪ Hermetic and custom designed package
< Applications >
▪ Range finding
▪ Surveying equipment
▪ Weapons simulation
▪ Laser radar
▪ Ceilometer
▪ Optical trigger
▪ Medical
