型番：Er-PULS-fs　メーカー：ALPhA NOV　商品コード：L003558

1560nm±10 / 150mW　Sub-100 fs Fiber Laser

波長: 1550nm-1570nm
出力: 150mW-
パルス幅: < 100 fs
冷却方法: Air

< New generation of sub-100 fs fiber laser at 1560 nm >
Er-PULS-fs, is a new product completing our PULS product line. This laser benefits from our legacy in modelling, designing of innovative fiber laser sources and components. Based on all-PM fiber frequency doubled femtosecond mode-locked oscillator, our laser offers a unique, monolithic solution for various applications.

< Features >
• Cost-effective
• Air-cooled, compact, robust optical integration
• Environmentally stable output
• Laser customization

< Applications >
• THz generation
• Multiphoton, THG microscopy
• Mid-IR generation
• Optical Coherence Tomography (OCT)

< Options >
• Fiber delivery
• SHG @780 nm

< Technical Specifications >
(Optical)
Average power: > 150 mW @ 40 MHz
Spectral width: > 40 nm
Pulse duration: < 100 fs
Repetition rate: 40 MHz
M²: < 1.2.
Ellipticity: > 0.92
Beam waist diameter: 2 - 5 mm
Output coupling: Free space (fibered delivery as an option)
Power stability: ~ 1% RMS
Polarization: Linear (PER > 20 dB)

(Electrical)
External interface: USB, RS232, output trigger
Software interface: ALPhANOV GUI, serial communication protocol
Compatibility & libraries: Ubuntu / Windows 7 / 10 ; DLLs-Hexa

(Mechanical)
Dimensions laser head / laser controller dimensions: 230 x 145 x 55 mm
