型番：　メーカー：OSRAM GmbH　商品コード：L001445

940nm Laser, TO-220 package

940nm Laser, TO-220 package
940nm Laser, TO-220 package
940nm Laser, TO-220 package
940nm Laser, TO-220 package
940nm Laser, TO-220 package
940nm Laser, TO-220 package
940nm Laser, TO-220 package
940nm Laser, TO-220 package
940nm Laser, TO-220 package
940nm Laser, TO-220 package
940nm Laser, TO-220 package
940nm Laser, TO-220 package
940nm Laser, TO-220 package
940nm Laser, TO-220 package

波長: 940nm-940nm
出力: 2000mW-2000mW
パッケージ: TO-220
テクノロジー: n/a

940nm Applications
• Pumping of solid state lasers (Nd: YAG, Yb: YAG)
• Medical and dental applications
• Soldering, heating, illumination
• Free space data transmission
• Energy transmission
• Testing and measuring applications

Features
• Efficient 940nm laser radiation source for cw and pulsed operation
• Reliable InGa(Al)As strained layer quantum-well structure
• New optimized single quantum-well structure
• Improved reliability, low treshold current, higher efficiency
• Small TO-220 package with efficient thermal coupling
• Included thermistor allows wavelength control by temperature
• Laser aperture 200 µm
• Cylindrical lens for correction of the vertical axis
