型番：　メーカー：TOPTICA Photonics AG　商品コード：L000908

Laser Diodes | 800nm-2810nm

Laser Diodes | 800nm-2810nm
Laser Diodes | 800nm-2810nm
Laser Diodes | 800nm-2810nm
Laser Diodes | 800nm-2810nm
Laser Diodes | 800nm-2810nm
Laser Diodes | 800nm-2810nm
Laser Diodes | 800nm-2810nm
Laser Diodes | 800nm-2810nm
Laser Diodes | 800nm-2810nm
Laser Diodes | 800nm-2810nm

波長: 800nm-895nm
出力: 140mW-140mW
パッケージ: TO-can
テクノロジー: DFB Laser and DBR Laser

800nm-895nm DFB & DBR Laser Diodes from Toptica. The data sheet attached details the following attributes: WLmin and WLmax denote the wavelength range accessible via temperature tuning. DFB Lasers (Distributed Feedback) DBR Lasers (Distributed Bragg Reflector) laser diodes operate in transverse and longitudinal single mode. Tuning can be achieved by varying either current or temperature. Single frequency operation is maintained over several hundred GHz without modehops. In the table, WL indicates the emission wavelength at 25°C. P is the maximum output power of the diode. for the most part accomplished without mode-hops. dL/dT states the tuning rate with respect to temperature. For maximum frequency stability of your DFB/DBR laser diode, we recommend TOPTICA's patented ColdPack housing. The ColdPack can accommodate any standard 9 mm or 5.6 mm laser diode within a TO-3 style package with integrated thermistor and thermoelectric coolers. The laser temperature can thus be precisely stabilized, or the diode can be cooled / heated rapidly, just as requested for your application. A remark "TO-3" indicates that the diode is already packaged in a TO-3 housing prepared for temperature control.

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ トプティカフォトニクス株式会社
