型番：　メーカー：QD Laser　商品コード：L000896

830nm Laser Diode, 210mW

830nm Laser Diode, 210mW
830nm Laser Diode, 210mW
830nm Laser Diode, 210mW
830nm Laser Diode, 210mW
830nm Laser Diode, 210mW
830nm Laser Diode, 210mW
830nm Laser Diode, 210mW
830nm Laser Diode, 210mW

波長: 830nm-830nm
出力: 210mW-210mW
パッケージ: TO-can
テクノロジー: Fabry-Perot

830nm laser diode from QD Laser. The QLF083x series is an 830 nm quantum well laser device designed for high output power application. The laser diode is mounted into a TO-56 header including a monitor PD and hermetic sealed with a flat glass cap.

FEATURES:
- 830 nm FP-LD
- 5.6mm TO-CAN package
- High output power of 210 mW and high slope efficiency
- Lateral single mode
- Including monitor PD
- Two types of pin assignments

APPLICATIONS:
- Particle inspections
- Measuring instruments

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ 京都府 株式会社光響
