型番：　メーカー：nLIGHT,INC.　商品コード：L000879

879nm, 120W from nLight Corporation

波長: 879nm-879nm
出力: 120W-120W
パッケージ: Pearl™ P16 Fiber Coupled Diode Lasers
テクノロジー: Fiber Coupled Module

879nm nLight 100W laser diode: Cascades: VSA Series

The Cascade VSA series is designed for Medical and Material Processing to optimize the demanding industrial requirements of continuous performance with ease of integration. nLIGHT’s Cascades™ vertical array product series is based on the Cascades™ actively, water-cooled, low thermal resistance package, which provides end users with state-of-the-art power, brightness and reliability. Our 1-cm wide, MOCVD grown GaAs or InP arrays consist of multiple transverse mode emitters, which provide low beam divergence and narrow spectral bandwidth. Cascades™ vertical stacked arrays are available in a wide range of wavelengths between 790 nm to 830 nm.
The design of these devices allows multiple packages to be vertically stacked, with a pitch of 1.8 mm, up to 20 bars high. Standard packaging footprint allows these stacks to easily integrate into your product.

Features:
- Patented nXLT™ diode protection for extended life
- High Power
- Industry-leading wall-plug efficiency >50%
- Low Smile Bars
- Fast Axis Lensing
- High Polarization Purity

Applications:
- BPH
- Hair Removal
- Materials Processing

見積りBOXへ入れる欲しい物リストに登録

メーカーWebサイトへ

価格	地域	代理店
要問い合わせ		丸文株式会社

879nm, 120W from nLight Corporation
