型番： メーカー：Photop Technologies 商品コード：L000080
532nm Laser Diode | 5mW
波長: 532nm-532nm
出力: 5mW-5mW
パッケージ: TO-can
テクノロジー: green laser diode
532nm laser diode from Photop Technologies are offered in TO-can packages. The specifications sheet defines the following key features, applications, and specifications. The typical operating current of these devices is 210mA. The typical operating voltage is specified at 1.9V. These 532nm devices have an integrated photodiode with a typical associated monitor current of 85 micro amps. Optical output power is 5mW. These diode lasers offer very high stability specified at +/-2% while at a constant temperature. Key features include mini sized packaging and low cost. Also, these devices offer an auto-power regulation. They are used primarily for laser displays and surveying equipment.
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
|
代理店が登録されていません |
|||
