型番：UMB200C020、UMB404P050、UMB500C040、UMB700P100、UMB700P200、UMB800C100　メーカー：Northrop Grumman Corporation　商品コード：L000628

Laser Diode Bars

Laser Diode Bars
Laser Diode Bars

Laser Diode Bar データシート.pdf

波長: 790nm-980nm
出力: 20W-200W
電流: 25A-175A
電圧: 1.7V-2.0V
パッケージ: Laser diode bar
テクノロジー: High power laser diode bar

CEO manufactures a full line of laser diode bars that are well-suited to a variety of applications. The laser diode bars feature proprietary epitaxial structures designed by the CEO technical staff and are available in a range of wavelengths.

Standard available wavelengths (nm): 790-820, 872-890, 930-950, 970-990 (custom wavelengths also available)
Available output power (CW): 100 W/bar
Available output power (QCW): 300 W/bar

CEO is well-positioned to handle high-volume requests for laser diode bars. Whether your request is for 1000 laser diode bars or hundreds of thousands of bars per year, CEO has the manufacturing capability to meet your needs.

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ ノースロップ・グラマン ジャパン
