型番: メーカー:QSI 商品コード:L000592
波長: 635nm-635nm
出力: 20mW-20mW
パッケージ: TO-can
テクノロジー: n/a
635nm QL63H5S-A/B/C is a MOCVD grown 635nm band InGaAlP laser diode with quantum well structure.
It's an attractive light source, with a typical light output power of 20mW for optoelectronic devices
such as Optical Leveler and Modules.
♦FEATURES
- Visible Light Output : λp = 635 nm
- Optical Power Output : 20mW CW
- Package Type : TO-18 (5.6mmφ)
- Built-in Photo Diode for Monitoring Laser Diode
価格 | 地域 | 代理店 | |
---|---|---|---|
要問い合わせ | 三基光学館 | ||
