型番: メーカー:QSI 商品コード:L000442

InGaAlP Laser Diode

波長: 670nm-670nm
出力: 5mW-5mW
パッケージ: TO-can
テクノロジー: n/a

670nm Model : QL67D6S-A/B/C InGaAlP Laser Diode
Quantum Semiconductor International Co., Ltd.

OVERVIEW:
The QL67D6S-A/B/C is an MOCVD grown 670nm band Gain-Guided type InGaAlP laser diode with quantum well structure. It's an attractive light source, with a typical light output power of 5mW for optoelectronic devices such as Bar Code Readers.

APPLICATION:
- Optical Leveler
- Laser Module
- Bar Code Readers

FEATURES:
- Visible Light Output : λp = 670 nm
- Optical Power Output : 5mW CW
- Package Type : TO-18 (5.6mmφ)
- Built-in Photo Diode for Monitoring Laser Diode

価格 地域 代理店
要問い合わせ 三基光学館
