型番：IMPULSE-HE　メーカー：Clark-MXR, Inc　商品コード：L003915

High-Average-Power High-Energy version of Model IMPULSE

High-Average-Power High-Energy version of Model IMPULSE
High-Average-Power High-Energy version of Model IMPULSE

IMPULSE-HE データシート.pdf

波長: 1030nm-
出力: 20W-
エネルギー: 40µJ-
パルス幅: sub-250fs, user adjustable between <250fs and >8ps

IMPULSE-HE is the second generation laser from the IMPULSE family that provides more pulse energy with the same salient features that our Model IMPULSE is famous for. It is built on the same all-diode-pumped, direct-diode-pumped Yb-doped fiber oscillator/amplifier system architecture capable of producing variable pulse energies in excess of 70μJ with user-adjustable repetition rates between single-shot and 25MHz.

IMPULSE-HE is based on a revolutionary new concept in mode-locked oscillator/amplifier technology. The Yb-doped fiber-oscillator/fiber-amplifier design combines the low noise performance of solid-state operation with the high spatial mode quality of fiber lasers.

IMPULSE-HE is a second generation, compact, robust, one-box source of femtosecond to picosecond pulses with the ease-of-operation, stability and reliability. All major parameters are fully computer controlled, enabling easy interface to a workstation or experimental setup. IMPULSE-HE is remotely accessible for control of all laser parameters and diagnostics.

Ideal for: NOPAs/OPAs pumping including UV to Mid-IR NOPAs to generate extremely short pulses,harmonic generators (2nd, 3rd and 4th), MHz high harmonic generation, electron microscopes, pump/probe and nonlinear spectrometers and micromachining workstations.


【Features】

Direct-diode-pumped Yb-fiber oscillator/amplifier design
All-diode pumped, all-solid state construction
Robust, one-box design
>20 Watts Average Power @ 1 MHz repetition rate
Repetition rate variable from single-shot to 25 MHz
Complete computer control and web enabled
High beam quality
Low noise, cw-pumped
High stability and longevity


【Applications】

Micromachining
Photopolymerization
Direct-write waveguides
High S/N pump/probe
OPA/NOPA pumping

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ AkiTech Leo株式会社
