型番:30.070.00058 メーカー:Artifex Engineering 商品コード:L003779

OPM150 100kHz Base Module

テクノロジー: CW

< Description >
This optical power monitor is USB powered and controlled. No external power supply is required. The enclosure is a solid body milled from full material. It is very robust and gives good shielding to electromagnetic interference. The base of the body has two tapped holes for mounting.
The unit is very compact with dimensions 60x81x36mm (WxLxH).

< Specifications >
Connectors: DB9 (detector head); USB (communication); BNC (voltage output)
Bandwidth: 100kHz
Measurement range: 1kV/A – 10MV/A
Sampling rate: 30S/s (via GUI software); 600S/s direct polling
Gain control: 5 gain ranges (1kV/A; 10kV/A; 100kV/A; 1MV/A; 10MV/A)
Accuracy: ±1%
Power supply: USB
Functions: graph and digital display modes, averaging

価格 地域 代理店
要問い合わせ 京都府 株式会社光響
