型番：PLDD-200-12-20-2x2　メーカー：Analog Modules　商品コード：L003654

200 Amp Pulsed Laser Diode Driver

電流: -200A
パルス幅: <20 µs to 300 µs

DESCRIPTION:
The PLDD-200-12-20-2X2 is an ultra-compact and light weight version of our standard 200 Amp pulsed current source designed to drive laser diode bars, arrays of laser diode bars, or any low impedance load. The unit features a high peak current of 200 Amps with a rise-time of <10 μs (load dependent) and a maximum pulse width of 300 μs. The pulse repetition frequency can be varied from single shot to 20 PPS. The output current amplitude can be controlled by either an analog voltage or an on-board potentiometer. The pulse width is controlled by the duration of the input trigger signal. Using the optional Universal Interface Board (UIB-01), the user has easy access to all control pins. Commonly used signals on the UIB-01 are available through BNC connections such as the input trigger and the current monitor which allows the user a real time view of the current. The PLDD-200-12-20-2x2 requires a user supplied +15 to +28 V input supply.

見積りBOXへ入れる欲しい物リストに登録

メーカーWebサイトへ

価格	地域	代理店
要問い合わせ		株式会社オプトサイエンス

200 Amp Pulsed Laser Diode Driver
