型番：Necsel NovaTru™ Power 520　メーカー：Necsel Communication＆Instrumentation Systems, Inc.　商品コード：L003593

Necsel NovaTru™ Power 520 Power Stabilized Laser Module

出力: 15mW-45mW
ビーム径: 1.8 x 0.6 mm
拡がり角: 0.8 x 1.3 mrad

This laser module offers ultra stable power performance with VBG locked-on linewidth and/or precise power control in the same compact footprint as our other NovaTru modules. It’s also available in multimode and single mode versions.

< FEATURES & BENEFITS >
Ultra Stable Output Power
Compact, Small Box Design
Low Power Consumption
Power Stabilized to <0.4%

< APPLICATIONS >
Raman Excitation
Flow Cytometry
Metrology
Spectroscopy
Semiconductor Processing

< Operating Specifications >
Spectral linewidth：TYPICAL 1-2nm
Wavelength stability (over 8 hours)：TYPICAL +/- 1nm
Optical power stability (over 8 hours)：TYPICAL <0.4% pk-pk
Noise (10Hz–100MHz)： TYPICAL < 0.2%rms
Adjustable Output Power：TYPICAL 10-90%
Beam quality (m^2 typical) vertical：TYPICAL 1.2
Beam quality (m^2 typical) horizontal：TYPICAL 1.1
Beam size vertical：TYPICAL 1.8mm
Beam size horizontal：TYPICAL 0.6mm
Beam aspect ratio：TYPICAL 3
Beam divergence—vertical：TYPICAL 0.8mrad
Beam divergence—horizontal：TYPICAL1.3mrad
Beam pointing stability (over 8 hours)：TYPICAL < 50µrad
Beam pointing accuracy：TYPICAL 1degrees
Polarization ratio：TYPICAL 100:1linear

< Electrical Specifications >
Case temperature：TYPICAL 10-40°C
Humidity (non-condensing)：TYPICAL 5-95%
DC input 1：TYPICAL 0.5A @ 9V
DC input 2：TYPICAL 2A @ 3V
Warm-up time (typical)：TYPICAL 10sec
Power consumption (typical/max)：< 12W
