型番: メーカー:QSI 商品コード:L000361

Diode Laser | 650nm TO-can 10mW

波長: 650nm-650nm
出力: 10mW-10mW
パッケージ: TO-can
テクノロジー: n/a

650nm QL65F5S-A/B/C is a MOCVD grown 650nm band InGaAlP laser diode with quantum well structure. It's an attractive light source, with a typical light output power of 10mW for optoelectronic devices such as Laser Pointer & Bar Code Reader.

APPLICATIONS
- Optical Leveler
- Laser Pointer
- Bar Code Reader

FEATURES
- Visible Light Output : λp = 650 nm
- Optical Power Output : 10mW CW
- Package Type : TO-18 (5.6mmφ)
- Built-in Photo Diode for Monitoring Laser Diode

価格 地域 代理店
要問い合わせ 三基光学館
