型番：MIR-PULS　メーカー：ALPhA NOV　商品コード：L003561

1800nm - 2100nm / >20mW　Sub-300 fs Tunable Fiber Laser Source

波長: 1800nm-2100nm
出力: 20mW-
パルス幅: < 300 fs
冷却方法: Air

< Tunable fiber laser source sub 300 fs; 1800 - 2100 nm >
MIR-PULS is a new product completing our PULS product line. This laser benefits from our legacy in modelling, designing of innovative fiber laser sources and components. Part of the PULS family product, MIR-PULS delivers 20mW of sub-300 fs TFL pulses at 40 MHz, over the spectral range of 1800-2100 nm. It offers a unique solution for applications such as bioimaging, optogenetics, spectroscopy or seed source for Thulium/Holmium based amplifier systems.

< Features >
• Cost-effective short pulse tunable source
• Air-cooled, compact, robust optical integration
• Environmentally stable output
• All PM fiber, alignment-free
• Laser customization

< Applications >
• Optogenetics
• Spectroscopy
• Bioimaging
• Th/Ho amplifier systems

< Options >
• SHG @ 920 nm

< Technical Specifications >
(Optical)
Wavelength: Tunable 1800 - 2100 nm
Average power: > 20mW
Spectral width: > 20 nm
Pulse duration: < 300 fs
Repetition rate: 40 MHz typ.
Output coupling: PM fiber (FC/APC & PC ; SC/APC & PC)
Power stability: 1% RMS
Polarization: Linear (PER > 15 dB)

(Electrical)
External interface: USB, RS232, output trigger
Software interface: ALPhANOV GUI, serial communication protocol
Compatibility & libraries: Ubuntu / Windows 7 / 10 ; DLLs-Hexa

(Mechanical)
Dimensions laser head: 30 x 30 x 9 cm
