型番：FiberMax785　メーカー：Blue Sky Research　商品コード：L003322

785nm / 5, 10 50mW　Fiber Pigtailed NIR Laser Module

785nm / 5, 10 50mW　Fiber Pigtailed NIR Laser Module
785nm / 5, 10 50mW　Fiber Pigtailed NIR Laser Module
785nm / 5, 10 50mW　Fiber Pigtailed NIR Laser Module
785nm / 5, 10 50mW　Fiber Pigtailed NIR Laser Module
785nm / 5, 10 50mW　Fiber Pigtailed NIR Laser Module
785nm / 5, 10 50mW　Fiber Pigtailed NIR Laser Module

FiberMax785 データシート.pdf

波長: 770nm-800nm
出力: 5mW-50mW
電流: 22mA-190mA
電圧: 1.6V-2.8V
テクノロジー: Fiber Pigtailed NIR Laser Module

< Description >
FiberMax785 is a fiber-pigtailed red laser module delivering superior performance for today’s demanding electro-optic applications. Based on Blue Sky Research laser packaging technology, the FiberMax785 provides excellent coupling efficiency and stability in a cost effective package. The thermally stable design of the FiberMax785, based on our standard FiberMAX packaging technology, is a proven, stable package with many thousands of lasers operating in demanding applications. The units are offered with Multimode, Polarization Maintaining Single Mode or Single Mode fiber, 3mm or 0.9mm jacketing and a range of collimator options.

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店

代理店が登録されていません
