型番：AP-AMP1 メーカー：AdValue Photonics 商品コード：L003221
1900-2100nm / 5W 2 Micron Tm Fiber Amplifier
波長: 1900nm-2100nm
出力: 5W-5W
テクノロジー: Tm Fiber Amplifier
エネルギー安定性: ±5% (8 hours at 25 °C)
冷却方法: Forced air
< Optical Characteristic >
Gain wavelength: 1900-2100 nm options
Output power: 5 W (higher or lower power available)
Power adjustment: 10-100% max.
Output power stability: ±5% (8 hours at 25℃)
Beam quality, M2: < 1.1
Output polarization: Random (option: linear polarization)
Input/Output fiber:
Input; SMF-28 single mode fiber, 3 mm jacket, 1 m length, FC/APC connector
Output; Optical fiber or fiber collimator options
(For special requirement, please contact AdValue Photonics for options.)
< General Characteristics >
Operating temperature: +10 to +35℃
Storage temperature: -10 to +70℃
Power requirement: AC 100~240V (50/60Hz)
Warm-up time: 10 minutes
< Features >
・Wide wavelength range
・Adjustable power level
・Near diffraction limited beam quality
・Turn-key system with no maintenance
< Applications >
・LIDAR
・Gas sensing
・Mid-IR generation
・Spectroscopy
・Test and measurement
・Research & development
