型番：AP-CW　メーカー：AdValue Photonics　商品コード：L003220

1950nm / 200mW　2 Micron CW Fiber Laser

波長: 1950nm-1950nm
出力: 200mW-200mW
テクノロジー: CW Fiber Laser
冷却方法: Forced air

< Optical Characteristics >
Operating mode: CW
Operating wavelength: 1950 nm (option: 1900-2100 nm)
Wavelength accuracy: ±5 nm nominal
Output power: 200 ｍW (higher or lower power available)
Power adjustment: 10-100% max.
Spectral linewidth: < 1 nm
Beam quality, M2: < 1.1
Output polarization: Random (Option: Linear Polarization)
Output fiber: SMF-28 single mode fiber, 3 mm jacket, 1 m length, no connector
(Customization options available)

< General Characteristics >
Operating temperature: +10 to +35℃
Storage temperature: -10 to +70℃
Power requirement: AC 100~240 V (50/60Hz)
Warm-up time: 10 minutes

< Features >
・Customizable operating wavelength
・Near diffraction limited beam quality
・Turn-key system with no maintenance

< Applications >
・LIDAR
・Gas sensing
・Mid-IR generation
・Test and measurement
・Research & development
