型番: メーカー:TOPTICA Photonics AG 商品コード:L000314

DFB Laser, 640nm-2810nm

波長: 640nm-795nm
出力: 140mW-140mW
パッケージ: TO-can
テクノロジー: DFB and DBR

640nm-795nm Distributed Feedback (DFB Laser) and Distributed Bragg Reflector (DBR) laser diodes operate in transverse and longitudinal single mode. The Toptica data sheet attached references the following specifications and features: This is achieved by incorporation of a frequency selective structure within the diode. Tuning can be achieved by varying either current or temperature. Single frequency operation is maintained over several hundred GHz without modehops. In the table, WL indicates the emission wavelength at 25°C. P is the maximum output power of the diode. for the most part accomplished without mode-hops. dL/dT states the tuning rate with respect to temperature. For further information e.g. regarding tuning by current, fast modulation, spectroscopic applications and locking to resonance lines, please inquire with our sales team. For maximum frequency stability of your DFB/DBR laser diode, we recommend TOPTICA's patented ColdPack housing. The ColdPack can accommodate any standard 9 mm or 5.6 mm laser diode within a TO-3 style package with integrated thermistor and thermoelectric coolers. The laser temperature can thus be precisely stabilized, or the diode can be cooled / heated rapidly, just as requested for your application. A remark "TO-3" indicates that the diode is already packaged in a TO-3 housing prepared for temperature control.

価格 地域 代理店
要問い合わせ トプティカフォトニクス株式会社
