型番：LDD-1125 メーカー： 商品コード：L003016
30 Amp Pulsed Laser Diode Driver, OEM Small Form Factor Module
メーカー希望小売価格: Request Price
Product Overview:
The LDD-1125 is an innovative laser diode driver that contains a specialized current source able to precisiondrive
laser diodes in continuous / modulated and pulsed or mixed operation. Equipped with optional laser power measurement circuitry (photodiode input), the LDD-1125-LPC can also be operated as a Laser Power Controller.
Core element of the LDD's internal current source is the generation of highly precise 333 ps timing PWM steps that results in high resolution and very low ripple current. The output is short-circuit safe and can be chopped for up to 40 kHz pulsed-mode operation. Driving low inductive loads, ultra short fall and rise times are achievable.
For ultimate laser diode protection the supervision of critical system values is directly implemented in hardware.
This results in very fast switch-off times (<8 μs) in case of limit value violation. The LDD-1125 also monitors laser
diode temperature (NTC thermistor input). The LDD-1125 is fully digitally controlled; its firmware is upgradeable to offer various communication options and to meet specific customer requirements.
