型番：MPL-7500　メーカー：　商品コード：L002855

7.5 Amps Output Current Laser Power Supply

メーカー希望小売価格: $469.00 電流: 7.5A-7.5A

Product Overview:
The "MP" series of Laser Diode Drivers and TE Temperature Controllers offers high performance while operating from a single output DC supply. It uses a single 15 pin D-sub connector for inputs and outputs, enhancing the reliability of the interface with your laser diode or TE module.
The MPL laser diode driver provides excellent stability during constant current, constant power, or modulated operation of your laser diode. Front panel 12-turn trimpots allow precise control of setpoint and limit current. The independent current limit offers an additional level of protection for your laser diode.
The MPL series has an internal control circuitry that turns the output on and off depending on the voltage at V+. When the voltage reaches the power up trip point, the module soft starts the laser diode. When the voltage reaches the power down trip point, the module shunts current around the laser diode, powering it down in a controlled fashion.
Optional accessories available for system development includes: CKL-103 A Connector Kit includes the appropriate 15 pin D-sub connector, hood and hardware. CAL-104 A Cable Kit includes one meter of cable soldered to a mating connector on one end and unterminated on the other.
The control electronics are designed for low noise operation. The power supply you select will directly affect the noise performance of the driver. Use only regulated linear supplies for optimum performance.

見積りBOXへ入れる欲しい物リストに登録

価格	地域	代理店
代理店が登録されていません

7.5 Amps Output Current Laser Power Supply
