型番：CrF-450TP、CrF-400SP、CrF-700SP、CrF-700SP-L　メーカー：Avesta Project Ltd.　商品コード：L002740

CrF: Femtosecond Cr:F Solid-State Oscillator

CrF: Femtosecond Cr:F Solid-State Oscillator
CrF: Femtosecond Cr:F Solid-State Oscillator
CrF: Femtosecond Cr:F Solid-State Oscillator
CrF: Femtosecond Cr:F Solid-State Oscillator
CrF: Femtosecond Cr:F Solid-State Oscillator
CrF: Femtosecond Cr:F Solid-State Oscillator

CrF データシート.pdf

波長: 1230nm-1270nm
出力: 400mW-800mW
エネルギー: 4nJ-20nJ
拡がり角: <2 mrad
エネルギー安定性: <2% rms (CrF-450TP、CrF-400SP、CrF-700SP)、<5% rms (CrF-700SP-L)
冷却方法: thermoelectric + closed-loop water chiller

【Description】

The CrF chromium-forsterite laser offers a unique active medium that radiates femtosecond pulses around 1250 nm. The 1250 nm region offers new horizons for multiphoton microscopy for brain and heart tissue studies.

The laser features an integrated Peltier TE-unit for crystal cooling to lower-than-room temperatures for higher average output optical power and precise temperature control. Three models of the laser feature SESAM self-starting with a fixed wavelength operation and one model features an electromagnetic starter and offers wavelength tunability. The CrF includes a built-in 15-W fiber pump laser and control unit. CW version of the CrF is available separately as the CrF-CW laser.

The CrF laser can also be used as a seed oscillator for building high power FREGAT Cr:F amplifiers also offered by our company.


【Features】

1230-1270 nm wavelength tuning range
Up to 800 mW output average optical power
More than 20 nJ per pulse
Integrated fiber pump laser
Down to 35 fs pulse duration
SESAM or electronic starter
