型番：　メーカー：Photonics Industries International Inc.　商品コード：L002681

Nanosecond Laser, 532nm, 480µJ

Nanosecond Laser, 532nm, 480µJ
Nanosecond Laser, 532nm, 480µJ
Nanosecond Laser, 532nm, 480µJ
Nanosecond Laser, 532nm, 480µJ
Nanosecond Laser, 532nm, 480µJ
Nanosecond Laser, 532nm, 480µJ

波長: 532nm-532nm

Nanosecond laser with high output power from Photonic Industries. Key features of the laser include Patented Intracavity Green Generation, Field Replaceable Pump Diodes, RS-232 Computer Control, and monolithic laser head is design is to be compact and rugged. Total pulse control of nanosecond laser with pulse rates from 1Hz to 500kHz with pulse duration of 40ns. Average output power up to 48 watts at 100kHz. With spatial mode of TEM00 and typical beam quality of M2<1.1 and divergence of less then 2.5mrad. Laser operation can also be triggered via a TTL input. Nanosecond laser energy output up to 480µJ with a wavelength of 532nm.

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ 北海道 レイチャーシステムズ株式会社
