型番:Plus、Plus 2 J、Plus 2.5 J メーカー:Amplitude Laser Inc. 商品コード:L002667

High Energy Nd:YAG Laser:Powerlite DLS Plus

波長: 266nm-1064nm
エネルギー: 160mJ-3000mJ
テクノロジー: Nd:YAG Laser
ビーム径: 12 mm
拡がり角: 0.45 mrad

The Powerlite DLS Plus Series is an ideal solution when higher levels of green energy are required for the pumping of Ti:Sapphire laser systems.

High energy, high repetition rate Ti:Sapphire systems are using multiplexed standard lasers as the amplifier pump source. When more energy is required, more lasers are needed.

The Powerlite DLS Plus 2 J and 2.5 J lasers are the best alternative to the complex relay imaging systems delivering the multitude of beams to the amplifier crystal. At 2 J and 2.5 J at 532 nm, the Powerlite DLS Plus Series is the industry leader in terms of energy and beam quality. This is made possible by the implementation of the Faraday Isolator between the oscillator and amplifier, which allows the amplifier to run at its peak performance.

< Key Features >
・Distributed intelligence power supply architecture.
・Rack mounted and modular components for easier maintenance and service
・New cooling group with active digital control for acurate temperature monitoring and improved thermal management
・LabView drivers available

< Applications >
Industry:
Material sorting (recycling)
Weld inspection
Cleaning
LIBS

Science:
LIDAR, LIF, LIBS, PLIF
Thomson Scattering
Laser Thermal Annealing
Pump Source

Medical:
Skin Surfacing
Tattoo Removal
Pump Source
Medical device manufacturing

< Specifications >
Energy (mJ):
[Plus]
1064 nm 3000
532 nm  1500 [Using Type II doubler]
355 nm 800 [Using Type I double]
266 nm 160

[Plus 2 J]
1064 nm -
532 nm  2000 [Using Type II doubler]
355 nm NA [Using Type I double]
266 nm NA

[Plus 2.5 J]
1064 nm -
532 nm  2500 [Using Type II doubler]
355 nm NA [Using Type I double]
266 nm NA
