型番:1064-220-M、1064-180-L、1064-150-M、532-150-M、532-120-L、532-100-M、355-40-M メーカー:Amplitude Laser Inc. 商品コード:L002531

Diode Pumped Nd:YAG Laser:Mesa HP

波長: 355nm-1064nm
出力: 150W-220W
テクノロジー: Nd:YAG Laser
ビーム径: 2.5 mm、2.6 mm
拡がり角: 6 mrad、8 mrad、9 mrad、11 mrad
エネルギー安定性: < 2 % RMS、< 3 % RMS
冷却方法: Air-water; water-water cooling option available

The Mesa HP Nd:YAG laser is designed to accomplish demanding tasks for a broad range of industrial and OEM applications. Our pumping technology and stable optical resonator design produce a laser beam with uniform energy distribution and high output power.

The high-quality profile, combined with high pulse energy and repetition rates, provide an ideal laser beam for micromachining applications.

< Key Features >
・1064, 532, 355 nm operation
・Smooth and symmetrical beam profile
・Highly efficient wavelength conversion
・Fist-pulse supression for consistent material processing
・Compact & rugged package designed for 24/7 operation
・Record 3 min. diode module replacement with no realignment necessary
・Proprietary optical cavity design for optimal beam quality

< Applications >
Industry:
Stent/Glass/PCB/Fine Metal Cutting
LCD/Solar Edge Deletion
Marking
Wafer Trimming
Micro-hole Drilling
Ceramics Scribing
Fine Wire Stripping
Diamond/Gemstone Processing

Science:
Ti:Sapphire pumping
Particle Image Velocimetry
Combustion Analysis
Laser Induced Fluorescence
LIDAR
Resonance Raman Spectroscopy
Chemical Analysis of Macromolecules
Laser Microprobe Analysis

< Specifications >
Wavelength (nm) / Power CW (W)
[1064-220-M] 1064 / 220
[1064-180-L] 1064 / 180
[1064-150-M] 1064 / 150
[532-150-M] 532 / n/a
[532-120-L] 532 / n/a
[532-100-M] 532/ n/a
[355-40-M] 355 / n/a
