型番：　メーカー：Spectra-Physics　商品コード：L002464

Nd:YAG Laser, Nanosecond, 1064nm, 1.25J

Nd:YAG Laser, Nanosecond, 1064nm, 1.25J
Nd:YAG Laser, Nanosecond, 1064nm, 1.25J
Nd:YAG Laser, Nanosecond, 1064nm, 1.25J
Nd:YAG Laser, Nanosecond, 1064nm, 1.25J
Nd:YAG Laser, Nanosecond, 1064nm, 1.25J
Nd:YAG Laser, Nanosecond, 1064nm, 1.25J
Nd:YAG Laser, Nanosecond, 1064nm, 1.25J
Nd:YAG Laser, Nanosecond, 1064nm, 1.25J
Nd:YAG Laser, Nanosecond, 1064nm, 1.25J
Nd:YAG Laser, Nanosecond, 1064nm, 1.25J

波長: 1064nm-1064nm
テクノロジー: Nd:YAG Laser

Nd:YAG laser with nanosecond pulse widths from Spectra-Physics. The nanosecond laser was designed for applications in pumping of dye lasers, Ti:Sapphire lasers, OPAs and OPOs; LIDAR; Remote sensing; laser-induced fluorescence; flow visualization; plastic and ceramic components marking; and laser cleaning and ablation. Digital signal processing (DSP) electronics in the laser provides a modern control system for the user. The graphical user interface (GUI) provides intuitive and simple controls for the Nd:YAG Laser system. Pulse repetition frequency of 10Hz with a pulse duration of 8-12ns provides high energy output. Nd:YAG laser wavelength is 1064nm with output energy up to 1.25J.

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ スペクトラ・フィジックス株式会社
