型番：AP-P-SF-1030　メーカー：AdValue Photonics　商品コード：L002450

1.03µm / 100W　Pulsed Single Frequency Fiber Laser

1.03µm / 100W　Pulsed Single Frequency Fiber Laser
1.03µm / 100W　Pulsed Single Frequency Fiber Laser
1.03µm / 100W　Pulsed Single Frequency Fiber Laser
1.03µm / 100W　Pulsed Single Frequency Fiber Laser

AP-P-SF-1030 データシート.pdf

波長: 1.03µm-1.03µm
出力: -100W
エネルギー: -1.2mJ
テクノロジー: Pulsed Single Frequency Fiber Laser
パルス幅: 2 ns to 300 ns (non-adjustable, factory selectable)
冷却方法: Water cooled

< Optical Characteristics >
Operation mode: Pulsed
Spectral linewidth: Single Frequency (single longitudinal mode)
Pulse repetition rate: 10 kHz to 1 MHz (non-adjustable, factory selectable)
Beam quality, M2: < 1.2
Output polarization: Linear Polarization
Output delivery: Free-space collimated beam ~ 1 mm diameter (beam expansion available)
(For special requirement, please contact AdValue Photonics for options.)

< General Characteristics >
Operating temperature: +10 to +35℃
Storage temperature: -10 to +70℃
Power requirement: AC 100~240 V (50/60Hz)
Warm-up time: 10 minutes

< Features >
・Single longitudinal mode
・High pulse energy
・Customizable operating wavelength
・Nanosecond pulses
・Near diffraction limited beam quality
・Turn-key system with no maintenance required

< Applications >
・LIDAR
・Frequency Conversion
・Mid-IR generation
・Spectroscopy
