型番：AP-1030P　メーカー：AdValue Photonics　商品コード：L002435

1030nm / 15W-100W　EVERESTpico 1 μm Picosecond Fiber Laser

波長: 1030nm-1030nm
出力: 15W-100W
エネルギー: 10 µJ-30 µJ
テクノロジー: Picosecond Fiber Laser
パルス幅: 15ps、50ps
冷却方法: Water cooled (portable chiller available as an option)

< Optical Characteristics >
Operation mode: Pulsed
Average power: 15 W, 30 W, 60 W, 100 W
Pulse energy: 10 µJ, 20 µJ, 30 µJ
Pulse repetition rate: 100kHz, 500 kHz, 1 MHz
Beam quality, M2: < 1.3
Output power stability: Within ±5%
Output delivery: Collimated output beam
(For custom requirements, please contact AdValue Photonics)

< General Characteristics >
Operating temperature: +10 to +30 ˚C
Storage temperature: +5 to +70 ˚C
Power requirement: AC 100~240 V (50/60Hz) (operating with AdValue Photonics Control Unit)
Warm-up time: 10 minutes

< Features >
・Picosecond pulses
・High pulse energy and peak power
・High repetition rate capability
・Near diffraction limited beam quality
・Rugged OEM package and compact size

< Applications >
・Laser cutting, drilling and scribing (glass, sapphire, silicon, silicon carbide, ceramics, nitinol stents, CFRP, PCD and CVD diamond)
・Laser thin film patterning (TCO, metal, thin film solar cells)
・2.5D surface shaping (metals, ceramics, plastics)
・Laser marking (glass, sapphire, silicon carbide, silicon, metals, plastics)
