型番：　メーカー：Emcore Corporation　商品コード：L002416

1550 NM, DFB Laser, CATV, RF

1550 NM, DFB Laser, CATV, RF
1550 NM, DFB Laser, CATV, RF
1550 NM, DFB Laser, CATV, RF
1550 NM, DFB Laser, CATV, RF
1550 NM, DFB Laser, CATV, RF
1550 NM, DFB Laser, CATV, RF
1550 NM, DFB Laser, CATV, RF
1550 NM, DFB Laser, CATV, RF
1550 NM, DFB Laser, CATV, RF
1550 NM, DFB Laser, CATV, RF
1550 NM, DFB Laser, CATV, RF
1550 NM, DFB Laser, CATV, RF
1550 NM, DFB Laser, CATV, RF
1550 NM, DFB Laser, CATV, RF

波長: 1528nm-1563nm
出力: 16mW-16mW
パッケージ: butterfly
テクノロジー: DFB Laser, CATV, RF

1528nm-1563nm The EMCORE laser lists the following Applications: CATV Broadcast Networks, Networks with Limited Fiber, Archtechtures Using Separate Optical Wavelengths to Carry Targeted Services. The 1754C DFB laser component is a Dense Wavelength Division Multiplexing (DWDM) laser for analog CATV applications. It features a distributed-feedback (DFB) device that has been designed specifically for radio frequency (RF) and CATV applications. The 1754C laser component has a wide temperature range for reliable performance in harsh node environments and narrow transmitter designs. It also features low adiabatic chirp to maximize signal quality in short and long lengths of fiber. The laser’s excellent inherent linearity minimizes degradation of the broadcast signals caused by quadrature amplitude modulated (QAM) channels.

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ エム・アールエフ株式会社
要問い合わせ 住友大阪セメント株式会社
