型番：　メーカー：m2k-laser GmbH (COHERENT / DILAS)　商品コード：L002397

1870nm mid-infrared diode laser

1870nm mid-infrared diode laser
1870nm mid-infrared diode laser
1870nm mid-infrared diode laser
1870nm mid-infrared diode laser

波長: 1870nm-1870nm
出力: 500mW-500mW
パッケージ: fiber coupled module
テクノロジー: n/a

1870nm The m2k laser attached is a mid-infrared diode laser module which is used in medical applications, illumination, materials processing or pumping of mid-infrared solid-state and disc lasers. The unique brightness and efficiency of the module is achieved by broad-area, gain guided lasers based on the (AlGaIn)(AsSb) material system, epitaxially grown on GaSb substrates. The module is designed for passive cooling and is equipped with a SMA905 connector. The module is based on the unique micro-optics technology of INGENERIC.

Advantages:
- high brightness
- nominal output of 500 mW
- fiber diameter 200 μm
- fiber NA 0.22
- compact package
- passive cooling
- standard and customized connector
- optional pilot beam @ 635 nm

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ 株式会社ブルーアロー(high-brightness TA, TAL products)
要問い合わせ 株式会社ルクスレイ(DILAS High-Power Products)
