型番：RT-CW-FP-x-1925 (sbcw1513 DN)　メーカー：Alpes Lasers S.A.　商品コード：L002153

QCL | 5319nm-5076nm

波長: 5319nm-5076nm
出力: 50mW-50mW
パッケージ: COC, HHL, TO-3
テクノロジー: QCL, quantum cascade laser

Fabry-Pérot (FP) QCLs do not have an integrated optical grating to select a single spectral mode. Therefore they emit multimode light in a broad range that an cover more than 10% of the central emitting wavelength.

FP-QCLs can operate at room temperature. The emission is in the same wavelength range as for DFB QCLs. i.e. from 740 cm-1 to 2390 cm-1 with similar threshold current and voltage. The variation of temperature has a low influence on the emission bandwidth which is mainly defined by the supplied current. FP-QCLs are well adapted when broad band emission is acceptable, for ex. in liquid spectroscopy, high power emitting sources, when no signal purity is required or for using the QCL with external cavities.  

FP-QCLs can be defined with the following parameters:
・the central wavelength is defined by the centroid of total emitted power.
・the bandwidth is defined as the wavelength range where 90% of the power is emitted.
・for the same laser, the central wavelength and the bandwidth can change in function of the operating current and voltage.
・the average (or peak, depending on the application focus) power is the total power integrated over the spectrum, at maximum working current and -30°C.

見積りBOXへ入れる欲しい物リストに登録

メーカーWebサイトへ

価格	地域	代理店
要問い合わせ		株式会社キーストンインターナショナル
