型番:MWIR DFB 4.34 µm QCL C-Mount メーカー:Adtech Optics, INC. 商品コード:L002113
波長: 4.34μm-
出力: -137.6mW
電流: -0.63A
電圧: -11.6V
パッケージ: C-Mount
テクノロジー: MWIR DFB QCL
C - MOUNTED DEVICE
OVERVIEW
・Conductively Cooled
・CW Operation
・Mount Dimensions (approx): 6 x 6 x 4 mm (excluding leads)
(LASER SPECIFICATIONS)
Process: DFB
Oper. Temperature: 15 – 45 °C
Facet Coating: Front None / Back HR
(ELECTRO–OPTICAL CHARACTERIZATION)
Driving Conditions;
Operation Mode: CW
Temperature: 15 °C
Electrical;
Thresh. Current: 0.35 A
Thresh. Voltage: 10.8 V
Laser Efficiency: 1.9 %
Optical;
Center Wavelength: 4.34 µm
Tuning Range;
Temperature: N/A nm/K
Current: 36.3 nm/A
Beam Divergence;
Typ. Fast Axis: 60 deg
Typ. Slow Axis: 40 deg
