型番： メーカー：FITEL 商品コード：L002076
1529nm-1611nm, 40mW, DWDM
波長: 1529nm-1611nm
出力: 40mW-40mW
パッケージ: butterfly
テクノロジー: DWDM
1529nm-1611nm FRL15DCWx series of DFB laser module is designed for long haul DWDM applications with external intensity modulator. The polarization maintaining fiber pigtail enables to directly connect a modulator without polarization control. The polarization state of output laser beam is maintained to a consistent orientation. A strained multi-quantum well DFB laser diode chip is integrated with optical isolator, thermo-electric cooler (TEC), thermistor and power monitor photodiode in an industry standard hermetically sealed 14 pin butterfly package. This laser module complies with telecom requirements described in TelcordiaTM GR-468 and is manufactured in an ISOTM9001 certified production line.
Features:
- High optical output power up to 40mW
- High side mode suppression ratio(SMSR)
- Selected wavelength according to ITU-T Grid, C and L-band available
- 50GHz spacing available
- Narrow linewidth available
- RoHS compliant package
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | 京都府 | 株式会社光響 | |
