型番: メーカー:Princeton Lightwave, Inc. (ARGO AI, LLC.) 商品コード:L002054

1530nm OEM laser module, 30W

波長: 1530nm-1530nm
出力: 30W-30W
パッケージ: OEM module
テクノロジー: high powered laser array

1530nm The Princeton Lightwave Integrated Laser Diode Pump Module provides collimated highbrightness optical pumping at 1470 nm or 1530 nm. This product employs precision beam combining of multimode single emitters based on PLI’s industry-leading InGaAs/InP laser diode device technology. The use of a module design based on single emitters enables high brightness in both CW and quasi-CW operation as well as excellent beam quality and high
reliability. The module’s architecture also provides significant advantages related to the thermal management of pump sources, and the sealed chassis ensures stable operation of these sources in harsh environments.

Features:
• “Eye-safe” operating wavelengths
• Available with 1470 nm or 1530 nm output
• High brightness
• High power in CW (30 W) and quasi-CW (50 W) operation
• Excellent beam quality
• Available with ultra-narrow spectral width (< 1 nm)
• Combined single emitter technology
• Sealed chassis design for harsh environment

Applications:
• Solid-state laser pumping
• Eye-safe SWIR illuminators
• Material processing
• Scientific equipment
