型番：　メーカー：Finisar Corporation　商品コード：L002018

1528nm-1605nm, 20mW, CML

1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML
1528nm-1605nm, 20mW, CML

波長: 1528nm-1605nm
出力: 20mW-20mW
パッケージ: butterfly
テクノロジー: CML

1528nm-1605nm Finisar’s DM200-01 butterfly transmitter module employs proprietary Chirp Managed Laser (CMLTM) technology and has been specifically designed to transmit 10Gb/s data over physical distances up to 200km. The module is comprised of a directly-modulated DFB laser chip and a co-packaged proprietary optical spectrum reshaper (OSR) passive optical element. The OSR component also provides a frequency locking function and allows operation on the ITU-T channels within ±2.5GHz with coverage across both Cband and L-band for DWDM versions. Also included in the standard butterfly footprint are 2 photo-detectors for power control and wavelength locking, together with 2 TECs for temperature stabilization. Key specifications for the optical and electrical characteristics,
physical requirements, environmental conditions and reliability/quality requirements are detailed in this document.
