型番: メーカー:QSI 商品コード:L000194
波長: 635nm-635nm
出力: 40mW-40mW
パッケージ: TO-can
テクノロジー: n/a
635nm QL63J5S-A/B/C-L is a MOCVD grown 635nm band InGaAlP laser diode with quantum well structure.
It's an attractive light source, with a typical light output power of 40mW for optoelectronic devices
such as Optical Leveler and Modules.
APPLICATION
- Bar Code Scanner
- Laser Module
FEATURES
- Visible Light Output : λp = 635 nm
- Optical Power Output : 40mW CW
- Package Type : TO-18 (5.6mmφ)
- Built-in Photo Diode for Monitoring Laser Diode
