型番：　メーカー：Wavespectrum Laser, Inc.　商品コード：L001838

1450nm Laser Diode, 500mW

波長: 1450nm-1450nm
出力: 500mW-500mW
パッケージ: c-mount
テクノロジー: n/a

1450nm Laser Diode is a 500mW device mounted on a C-mount package from Wavespectrum Laser. This device offers up to 0.5 Watts of optical output power and is referenced for medical laser treatment applications from the attached specficiation sheet. This is a high power 1450nm device. Key specifications in the data sheet include an emitter area of 100 microns by 1 micron. Temperature tuning coefficient for these devices is specified at 0.3nm per degree Celsisus. The slope efficiency of these 1450nm diode lasers is 0.3mW per mA. Threshold current for these devices is stated at 60 mA with a nominal operating current of 2.5 Amps. Operating voltage is specified at 1.3 volts.

見積りBOXへ入れる欲しい物リストに登録

メーカーWebサイトへ

価格	地域	代理店
要問い合わせ	京都府	株式会社光響

1450nm Laser Diode, 500mW
