型番：DFB-1xxx-C5-2-2.5-xx-x-x-x-xx-x　メーカー：Applied Optoelectronics, inc.　商品コード：L001780

Coaxial Pigtail of MQW-DFB Laser for SONET CWDM transmission

Coaxial Pigtail of MQW-DFB Laser for SONET CWDM transmission
Coaxial Pigtail of MQW-DFB Laser for SONET CWDM transmission

DFB-1xxx-C5-2-2.5-xx-x-x-x-xx-x データシート.pdf

波長: 1270nm-1610nm
出力: 2.0mW-
パッケージ: 1.2 meter SMF-28 Fiber Pigtail、5.6-mm TO-style package
テクノロジー: DFB Laser

【Description】

The DFB-1xxx-C5-2-2.5-xx series of MultiQuantum Well (MQW) Distributed Feedback (DFB) lasers have been designed specifically to satisfy the requirements of SONET CWDM transmission. The devices feature high output power and wide operating temperature range. Their uncooled, hermetically sealed, coaxial fiberpigtailed packages are a cost-effective means of providing a high-speed light source for intermediate-reach and long-reach applications.


【Features】

Advanced Multiple Quantum Well (MQW) Distributed Feedback (DFB) Laser Design
High-speed up to 2.5 Gbps
Engineered Specifically for SONET transmitter applications
Low-Cost Uncooled Laser Technology
1.2 meter SMF-28 Fiber Pigtail
5.6-mm TO-style package


【Applications】

SONET 2.5 Gbps transmitter
Intermediate and long-distance fiberoptic transmitter
