型番： メーカー：QD Laser 商品コード：L001716
1122nm Laser Diode, 100mW
波長: 1122nm-1122nm
出力: 100mW-100mW
パッケージ: Butterfly
テクノロジー: DFB Laser
1122nm laser diode from QDLaser, QLA1x61-xxA0, is a distributed feedback (DFB) laser with integrated semiconductor optical amplifier (SOA) for use in seeder and sensing applications. The laser is assembled into a 14-pin butterfly package with an optical isolator and a thermo-electric cooler.
FEATURES:
- High fiber output power >100mW
- Single longitudinal mode operation
- 1064, 1122 and 1188nm
- Fiber-pigtailed 14-pin butterfly package
- TEC and Optical isolator integration
- Polarization maintaining fiber integration
APPLICATIONS:
- Seeder
- Sensing
- Wavelength Conversion
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | 京都府 | 株式会社光響 | |
