型番：　メーカー：OSRAM GmbH　商品コード：L001596

905nm Laser Diode | 4W

905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W
905nm Laser Diode | 4W

波長: 905nm-905nm
出力: 4000mW-4000mW
パッケージ: TO-can
テクノロジー: high power pulsed

905nm laser diode by Osram includes the following features referenced on the attached data sheet. Optical peak power of up to 4W at laser wavelength 905 nm. Suited for short laser pulses from 1 to 100 nsec with a laser aperture 60 microns × 2 microns. The device is housed in a cost effective plastic package for high volume applications. Applications include hand-held laser range finders (LRF) for golfers, hunters, civil engineers. Also referenced on the data sheet for this Osram 905nm device are automotive applications (Adaptive Cruise Control) and (ACC) pre-crash detection, collision avoidance, and adaptive rear lighting. Additionally, traffic surveillance: laser speed gun, traffic recording, vehicle classification, and distance measurement as well as fog detection.

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ オスラム　ジャパン株式会社
