型番：　メーカー：OSRAM GmbH　商品コード：L001590

High Powered 905nm, 90W array

High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array
High Powered 905nm, 90W array

波長: 905nm-905nm
出力: 90W-90W
パッケージ: array
テクノロジー: high power laser array

905nm Features of this Osram laser incldude: 12 individually addressable pulsed lasers, monolithic laser die with 260 μm channel pitch, aperture of each laser channel 200 μm × 10 μm, nanostack laser technology including multiple epitaxially stacked emitters. Also, optical peak power up to 75 W per laser at laser wavelength 905 nm. AR-coated glass window with integrated heater for wavelength stabilization and operating temperature range -40 to +105°C.

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ オスラム　ジャパン株式会社
