型番：　メーカー：Superlum Diodes Ltd.　商品コード：L001470

1180nm Diode Laser, 1mW

1180nm Diode Laser, 1mW
1180nm Diode Laser, 1mW

波長: 1180nm-1180nm
出力: 1mW-1mW
パッケージ: Buttefly
テクノロジー: SLED

1180nm Laser Diode is an SLD type device. The specification sheet attached refers to applications which include optical sensing, optical coherence tomography, and optical measurement. Key features of this 1180nm diode laser include a flat spectrum with very small Fabry-Perot modulation depth and maximum parasitic secondary coherence subpeaks intensity below -20 dB (10 log). Packaging is butterfly and the specified optical output power is 1mW. Additional & customized items include PD monitors and PM fiber pigtails, as well as polarized or pseudo-depolarized* output. Also referenced are =FC/APC terminated pigtails. Diode laser light is launched into the fiber with its polarization oriented at 45° to the birefringent axes.
