型番： メーカー：DILAS / COHERENT (DILAS High-Power Products) 商品コード：L001373
915nm Laser Diode
波長: 915nm-915nm
出力: 120W-120W
パッケージ: multi-bar module
テクノロジー: multi-bar high power array
915nm Laser Diode from DILAS laser is a 400 micron multi-bar array. This device references the following specifications and details on the data sheet. This diode laser is conduction cooled. It is a fiber-coupled multi-bar module. Key features include single wavelength of 915nm and a high coupling efficiency. Also, high optical output power is specified at 120Watts. Thermal interface is maintained by the base-plate. The optical output power is scalable. Also specified is a straight fiber output 0 or 90 degrees. Threshold current is specified at less than 7.5 amps and the operating current is specified at less than 60 Amps. The operating voltage of these 915nm laser diodes is specified at less than 6 volts.
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | 株式会社ルクスレイ | ||
