型番： メーカー：Princeton Lightwave, Inc. (ARGO AI, LLC.) 商品コード：L001225
820nm, 4mW, Superluminescent
波長: 820nm-820nm
出力: 4mW-4mW
パッケージ: butterfly
テクノロジー: SLED
820nm SUPERLUMINESCENT DIODES
Based on Princeton Lightwave’s advanced high power angled ridge waveguide structure platform, we have developed a series of products to meet a wide range of application needs. This 4 µm ridge, angled chip, in a GaAs structure for 820nm, is packaged in a thermo-electric cooled standard butterfly package and can be pigtailed with either SMF or polarization maintaining fiber (PMF).
Features:
- Wide Bandwidth: 20 nm FWHM
- Low Noise Ripple: 3.5% @ 4 mW
Applications:
- Fiber Optic Gyroscope
- Medical Diagnostic Equipment
- Instrumentation
