型番：M1F-SS2.1　メーカー：DILAS / COHERENT (DILAS High-Power Products)　商品コード：L001170

808nm, 40 Watt Fiber Coupled Laser Diode Module, Single Bar Source

808nm, 40 Watt Fiber Coupled Laser Diode Module, Single Bar Source
808nm, 40 Watt Fiber Coupled Laser Diode Module, Single Bar Source
808nm, 40 Watt Fiber Coupled Laser Diode Module, Single Bar Source
808nm, 40 Watt Fiber Coupled Laser Diode Module, Single Bar Source

メーカー希望小売価格: Request Price 波長: 808nm-808nm
出力: 40W-40W
パッケージ: Fiber Coupled Module
テクノロジー: Single Bar Module

Product Overview:
DILAS Model M1F-SS2.1 Laser Modules
These model M1F-SS2.1 fiber coupled laser diode modules from DILAS / Coherent are conduction cooled, 808nm single bar modules in a small footprint sealed package. These modules offer a 200µm core SMA-905 output with free standing fiber tip. They offer the user high coupling efficiency and high brightness at an 808nm center wavelength.

High Power 808nm Source with Excellent Efficiency
These modules are specified to deliver 40 Watts of CW output power and deliver a slope efficiency in excess of 0.80 watts of optical power per ampere of input power. They typically have a temperature tuning ratio of just under 0.3 nm per degree Celsius. These units are offered with pre-configured control electronics and mounting chassis from OsTech, and are typically available on a 3 to 4 week lead time.
