型番：ARR181P1100、ARR181P1800、ARR181P2000、ARR181P2200、ARR181P2600、ARR181P3600、ARR181P4000、ARR181P5200　メーカー：Northrop Grumman Corporation　商品コード：L001165

11, 18, 20, 26-Bar X-Stretch G3 Packages

11, 18, 20, 26-Bar X-Stretch G3 Packages
11, 18, 20, 26-Bar X-Stretch G3 Packages

G3 Package データシート.pdf

波長: 790nm-1550nm
出力: 1100W-5200W
電流: 95A-175A
電圧: 19.8V-52.0V
パッケージ: G-package
テクノロジー: High power laser diode array

CEO offers a stretched version of the industry-standard G Package that serves as a platform for up to 26 QCW bars. This configuration can produce up to 7.8 kW of peak output power. CEO offers these arrays with many values of bar-to-bar pitch (400 µm, 800 µm, 1.2 mm, 1.7 mm).

The X Stretch G Package mounts easily into laser systems or direct-diode applications. It is available in any of CEO’s standard wavelengths (790-820 nm, 872-890 nm, 930-950 nm), and custom wavelengths are also available. Many configurations are available with fast-axis collimation, with divergence values less than 0.2° (FWHM).

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ ノースロップ・グラマン ジャパン
