型番： メーカー：NOLATECH 商品コード：L000111
405nm Blue Laser, 10mW, butterfly
波長: 405nm-405nm
出力: 10mW-10mW
パッケージ: butterfly
テクノロジー: blue laser diode
405nm Laser Diode 10mW from Nolatech: This blue laser diode is single mode module designed for optical measurement and communication. The laser is packaged in 14-pin standard butterfly package with monitor photodiode and thermo-electric cooler (TEC). Module is pigtailed with 0,7-1,0 m of single mode polarization maintaining fiber and connectorized by FC/PC connector.
Key Features:
- Optical output: 10mW
- Efficient coupling into single mode fiber
- CW or pulsed operation
- SM or PM Fiber (ø0.9mm)
- FC-PC connector
- 14-pin butterfly package
- Internal monitor PD and Thermistor
