型番：MCS056C060、MCS056C080、MCS056C100 メーカー：Northrop Grumman Corporation 商品コード：L001061
1-Bar MCC Packages
波長: 780nm-975nm
出力: 60W-100W
電流: 68A-101A
電圧: 1.7V-1.8V
パッケージ: MCC package
テクノロジー: High power laser diode array
The single-bar microchannel-cooled package is available with a CW or QCW bar. The CW configuration is rated at 100 W and the QCW configuration has a maximum peak power rating of 300 W. This package features state-of-the-art cooling that enables superior heat extraction, thereby allowing for higher output powers than are available with other array styles.
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | ノースロップ・グラマン ジャパン | ||
